LC/UPC 12-Fiber OM3 50/125 Multimode Jacketed Fiber Pigtail

0.5m LC/UPC to Unterminated 12 Fibers Jacketed Color-Coded OM3 50/125 Multimode 0.9mm 12-Color Fiber Pigtail

JBX00105

$53.70
In Stock|0 Reviews|0 Questions
Free Shipping: Free Standard Shipping on Orders Over $99
Ships From: Danville, CA 94526, Fort Worth, TX 76028, Beaufort, SC 29902
Custom Available: Available in Custom Lengths
TAA Compliant: Yes
Warranty: 90 Day Limited Warranty

Professional-grade OM3 12-fiber pigtail with LC/UPC termination and 12-color coded jacketing. Designed for high-performance multimode networks with ≤0.35dB insertion loss. TAA compliant, RoHS certified, and available in custom lengths.

Description

The JBX00105 OM3 12-Fiber Pigtail is a professional telecommunications component engineered for demanding multimode fiber optic network deployments. This pre-assembled pigtail combines precision engineering with practical design features that streamline installation and reduce network downtime. Key Technical Specifications: This assembly features OM3 50/125 multimode fiber with individual 12-color coded strands for efficient network management and quick visual identification. The LC/UPC connector end provides standard industry compatibility, while the unterminated end accommodates custom splicing or future connection requirements. At 0.5 meters, this length is ideal for patch panel installations, equipment backhauls, and test environments. Performance Metrics: With insertion loss of ≤0.35dB (typical 0.15dB) and return loss exceeding 20dB, this pigtail meets enterprise-class performance standards. G.657.A1 fiber specifications ensure reliable operation at both 850nm and 1300nm wavelengths, with attenuation rates of 3.0 dB/km at 850nm and 1.0 dB/km at 1300nm. Compliance & Quality Assurance: TAA compliant and RoHS/ELV certified, this product meets stringent government procurement requirements. Manufactured across Taiwan, US, and China facilities, it carries a 90-day limited warranty and is backed by proven quality standards. Customization & Logistics: Custom lengths are available for specialized applications. The product ships free on orders exceeding $99 from multiple US fulfillment centers (Danville CA, Fort Worth TX, and Beaufort SC), ensuring rapid delivery. Applications: Ideal for data centers, enterprise campus networks, telecommunications hubs, and laboratory testing environments requiring high-density fiber infrastructure. Manufacturer Details: Harmonization Code: 8544.70.0000 | Commodity: Optical Accessory | Case Packaging: 10x10x10

Technical Specifications

ColorAqua
Fiber Strands12 Strands
ComplianceRoHS / ELV
Country of ManufactureTW, US, CN
Fiber ConnectorsLC/UPC, Unterminated
DirectiveEU directive 2002/95/EC (RoHS)
TAA CompliantYes
Quick Descriptiom0.5m LC/UPC 12F OM3 Pigtail 0.9mm 12-Color
Hamonization Code8544.70.0000
Fiber CoreOM3 50/125 Multimode
Length Meters0.5m
PolarityStraight Through
Glass FiberG.657.A1
Outside Diameter0.9mm
StandardsTIA-492AAAC / ISO-11801 OM3
Insertion Loss≤0.35dB (0.15dB Typ.)
Return Loss≥20dB
Attenuation850 nm: 3.0 dB/km or at 1300 nm: 1.0 dB/km
JacketingJacketed
